Model : OPT-RY-2MB-3680-AI-WDR-60F-MT
2 Megapixel 5-50 mm Motorized High quality imaging with progressive scan CMOS Real time Support SMART H.265/H.264 coding Up to 80M IR distance Bullet network camera
Video
- Imaging Device: 1/2.8
- Effective Pixels: 2MP 1920(H)×1080(V)
- Scanning System: Progressive CMOS
- Min. Illumination: Color 0.002lux @ F1.6(AGC ON) ; B/W 0 lux @ IR ON
Lens
- Focal Length (Zoom Ratio): 5 ~ 50 mm
- Max. Aperture Ratio: F No. 2.0±5%
- Angular Field of View: Horizontal: 49-7 °, Vertical:27-5 °, Diagonal: 57-8°
- Min. Object Distance: 0.2m~∞
- Lens: Motorized(Ø14)
Operational
- IR Viewable Length: Up to 80m
- Camera Title: On/Off
- Day & Night: IR cut filter with auto switch（Day/Night/Auto/Image/Schedule）
- Backlight Compensation: Off/On (5 Zone)
- Wide Dynamic Range: WDR
- Digital Noise Reduction: 3D DNR
- Motion Detection: Off/On (8 Level)
- Privacy Masking: Off/On (4 Zone, Rectangle)
- Gain Control: Auto
- White Balance: Auto/Manual/Indoor
- Electronic Shutter Speed: 1/5 ~ 1/20000s
- On-Board Storage: Micro SD slot, up to 256GB
- Alarm: 1 input, 1 output
- Audio: 1 input (RCA), 1 output (RCA)
- Hardware Reset: Yes
- Smart Feature: Face Recognition, Pedestrian & Vehicle, Perimeter Intrusion, Line Crossing, Object Detection, Crossing Counting, Heat Map, Crowd Density, Queue Length, License Plate, Rare Sound, Intrusion, Region Entrance, Region Exiting
Network
- Ethernet: RJ45(10/100BASE-T)
- Video Compression Format: H.265/H.264
- Resolution: Mainstream
1080P(1920×1080), 960P(1280×960), 720P(1280×720)
Substream
720P(1280×720), VGA(640×480),QVGA(320×240)
Mobilestream
VGA(640×480), QVGA（320×240） - Max. Framerate: 50Hz: 50fps@2MP / 60Hz: 60fps@2MP
- Video Quality Adjustment: 256Kbps ~ 8Mbps
- Bitrate control method: CBR/VBR
- IP: IPv6
- Streaming Capability: Triple-Stream(Main/Sub/Moile)
- Protocol: TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP
- Web browser: IE10/11, Safari V12.1 above, Firefox V.52 above, Google chrome V.57 above, Edge V.79 above
- Streaming Method: Unicast/Multicast
- Application Programming Interface: ONVIF( Profile S/G/T/M)
Electrical & Mechanical
- Input Voltage / Current: D12V/POE(IEEE802.3af)
- Material: Metal
