Model : OPT-041ST-1HD-PVR
General
- OSD Language : English/French/Spanish/Portuguese/German/Italian/Greek/ Danish/Finnish/Russia/Hebrew/Turkish/Bulgarian/Arabic/ Korean/Japanese/Thai/Hindi/Romanian/Dutch/Polish
- Dimension (WxDxH): 300X227X53mm
- Input Voltage/Current: DC48V/1.2A
- Power consumption (excluding hard disk): 5W
- Operating Temperature/Humidity: Temperature: -10°C~+50°C (14°F ~ 122°F)
Humidity: Less than 90%RH
Perfomance
- Compression: Audio: G.711A,G/711U
Video : H.264/H.264+/H.265/H.265+ - Frame rate: 4K:30fps – 4MP:60fps – 2MP:120fps
- AI: yes
- Event: MD(Sensitivity Level 1~8)
Videlo loss
Beep, Email, Push notification to Mobile APP
- Playback function: Fast forward / backward (2x, 4x, 8x,16x)
Slow forward (1/2x, 1/4x, 1/8x,1/16x) - Playback: Max 4CH playback
- Fisheye: Use WEB CMS, device does not support
- Local: UI5.0
- WEB: IE10/11, Safari V12.1 above, Firefox V.52 above Google chrome V.57 above ,Edge V.79 above
- Mobile viewer: Optier pro
- Push Notification: Yes
Interface
- P/W Reset: Factory Reset : Press 10 seconds
- VGA: (1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 ）
- HDMI: (1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 , 2560*1440, 3840*2160/EDID）
- POE: 4*RJ45、802.3at/af
- Ethernet: 1 RJ45 10/100 Base-T
- USB: “USB2.0*1(front) , USB2.0*1+(rear)”
- Audio out: 1
- HDD: 1 SATA HDD, up to 10TB
Video
- Resolution: 8MP, 5MP, 3MP, 2MP(1080P), 1.3MP(960P), 1.0MP(720P)
- Inputs: 50Mbps
- Out: 48Mbps
